Model K-C3.5L
Model K-C3.5L
Service Training
Slide 1
K-C3.5L: Started 26 November, 2010
First draft: 2 December, 2010
Release 3 December, 2010
8 December, 2010: Several slides modified for easier Chinese translation. No
content changes.
1
