Quadra-Fire EXCURSION-I Installation Manual page 6

Multi-Purpose Tool - Shipping Location
MULTI-PURPOSE
TOOL SHIPPED ZIP-
TIED IN THIS AREA OF
THE APPLIANCE
Figure 2.2 Multi-Purpose Tool shipping Location
• Remove multi-purpose tool by cutting and discarding
zip-tie.
• See Figure 2.3 for multi-purpose tool storage.
• See Figure 2.1 for multi-purpose tool features / functions.
Quadra-Fire • EXCURSION-I, EXCURSION-II, EXCURSION-III Installation Manual • 2538-980 Rev. E • 5/19
6
Multi-Purpose Tool - Storage Options
OPTION A
Multi-purpose tool can be
stored behind the appliance
front.
MULTI-PURPOSE TOOL
OPTION C
Multi-purpose tool can be stored in appliance manual
bag.
Figure 2.3 Multi-Purpose Tool Storage Options
DO NOT store appliance manual bag in or around
the appliance.
NOTE: This is not an option for
all Inside Fit (INFIT) fronts.
OPTION B
Multi-purpose tool can be
stored behind the surround.
