Quadra-Fire EXCURSION-I Installation Manual page 46

MODELS: EXCURSION-III
EXCURSION-III SRV LOGS
LOG ID SRV PART #
1 SRV2539-711
2 SRV2539-712
3 SRV2539-713
4 SRV2539-714
5 SRV2538-715
6 SRV2539-716
7 SRV2538-717
8 SRV2539-718
NOTICE: To simplify the installation process, use
Figure 25 to positively identify each individual log
before beginning installation.
PILOT HOOD
B
A
Figure 26. Empty Firebox with Front Hearth Installed
LOG #1: Place burnout end of log #1 against the left side of pin B and the bark end between the grate and refractory. Slide
the log back until it contacts the back of the firebox. Rotate the log (bark end) clockwise unit it contacts the side refractory.
The log will be in contact with the firebox back, pin B and the side refractory. See Figure 28.
LOG #2: Place the bottom right end of log #2 against pin F and the left end of the log on the flat spot of log #1. Push the
log back so that it contacts the air scoop. See Figure 29.
PILOT HOOD
1
B
Figure 28. Log #1 Installed
Quadra-Fire • EXCURSION-I, EXCURSION-II, EXCURSION-III Installation Manual • 2538-980 Rev. E • 5/19
46
MOLDED LOG #
39-1
39-2
39-3
39-4
39-5
39-6
39-7
39-8
AIR SCOOP
G
F
E
C
D
1
Figure 25. Log Identification - Excursion-III
GRATE
H
BASE REFRACTORY
Figure 27. Side Profile Grate Location Reference
Figure 29. Log #2 Installed
4
2 3
5
BASEPAN
7/8 in.
2
F
1
8
7
6
