Quadra-Fire EXCURSION-I Installation Manual page 10

DECORATIVE FRONT - TUSCAN ARCH
*
NOTICE: 1/2 inch gap must be maintained
or components will overheat.
F
E
*
G
EXCURSION-I
EXCURSION-II
EXCURSION-III
Figure 3.3 Decorative Front Dimensions - Tuscan Arch
Quadra-Fire • EXCURSION-I, EXCURSION-II, EXCURSION-III Installation Manual • 2538-980 Rev. E • 5/19
10
in. 27-5/16
TA-EXC25
mm 694
in. 32-5/16
TA-EXC30
mm 821
in. 33-9/16
TA-EXC35
mm 852
D
A
A B C
12-1/16 3-1/4
306 83
15-9/16 3-1/4
395 83
18-13/16 3-1/4
478 83
D E F
31 20 19-1/2
787 508 495
36 23-1/2 23
914 597 584
41 27 26-1/2
1041 686 673
B
C
G
1/2
13
1/2
13
1/2
13
