SMA Solar Technology AG
4
Mounting
4.1 Selecting the Mounting Location
Danger to life due to fire or explosion.
• Do not install the Sunny String-Monitor on flammable construction materials.
• Do not install the Sunny String-Monitor near highly flammable materials.
• Do not install the Sunny String-Monitor in potentially explosive areas.
• Do not install the Sunny String-Monitor in an emergency exit path, or in a living or office area.
• Choose a location which can support the weight of the Sunny String-Monitor.
• Choose a location with low interference field strengths.
• Mount the Sunny String-Monitor so as to allow easy access for service work.
• Mount the Sunny String-Monitor so that it is protected from direct irradiation.
• Mount the Sunny String-Monitor so that it is as protected from rain as is possible.
• Provide for external strain relief.
• Mount the Sunny String-Monitor level on a wall or a stand, so that the connection area is
pointing downward.
• Do not mount the Sunny String-Monitor flat on its back or leaning.
Example:
In the case of a rack-mounted PV array, the Sunny String-
Monitor can ideally be positioned directly behind the PV
array in the shadow.
Technical Description
4 Mounting
SM A
SSM-TEN103132
17
