5

Mounting the Device

5.1 Mounting and Installation Location Requirements
Note the following information on the mounting / installation location of the Sunny WebBox:
• The Sunny WebBox is only suitable for installation in enclosed spaces.
• The ambient temperature must be between –4 °F and 149 °F (–20 °C and +65 °C).
• Protect the Sunny WebBox from dust, wet conditions, corrosive substances and vapors.
• Observe the minimum clearances in order to
guarantee sufficient heat dissipation.
Top
Side
Bottom
• Do not cover the Sunny WebBox.
• The Sunny WebBox requires a 100 V...240 V
power outlet.
• Check the mounting location for the presence of
current-carrying cables. If there are current carrying
cables at the mounting location, select a different
mounting location.
• The distance from the Sunny WebBox to the inverters may not be greater than the maximum
permitted distance of the corresponding plant communication type. Note the specifications in
the respective sections.
• During installation, make sure there is optimal reception for the transmission paths.
• Certain ambient conditions can reduce the connection quality and data transmission speed
between Bluetooth devices.
– Mount or install the Bluetooth device at a distance of at least 3
– WLAN devices
– Microwave ovens
– Other devices that use the 2.4 GHz frequency band
Installation Guide
2 in. (5 cm)
13
⁄ in. (1 cm)
32
6.0 in. (15 cm)
Mounting the Device
1
⁄ ft. (1 m).
4
SWebbox20-IUS102910 21
