UG-916

ORDERING INFORMATION

BILL OF MATERIALS

Table 9. EVAL-ADM2582EEMIZ
Quantity Reference Designator
4 RR7, R8, R9, R10
1 R11
1 RT
1 RT1
3 C8, C9, C13
5 C4, C6, 14, C15, C17
4 C2, C10, C12, C16
3 C1, C7, C18
2 C3, C5
1 J2
1 J3
1 J4
1 LTC1
1 R1
1 R2
1 R3
1 R4
1 R6
3 LK1, LK6, LK9
3 LK3, LK5, LK7
1 U1
1 U2
2 LK2, LK3
1 DI
1 D1
1 D2
1 C19
11 RXD, RE, DE, DI, A, B, Z, Y,
VDD, GND1, GND2
EVAL-ADM2582EEMIZ/EVAL-ADM2587EEMIZ User Guide
Description
Resistors, size 0805 (not inserted)
Resistor, 0 Ω, size 0402 (not inserted)
Resistor, 120 Ω, size 0805 (not inserted)
Resistor, 120 Ω, size 0805 (not inserted)
Capacitors, size 0805, 10 µF
Capacitors, size 0805, 100 nF
Capacitors, tantalum, 10 µF
Capacitors, size 0603, 100 nF
Capacitors, size 0603, 10 nF
Power connector, 2-pin terminal block
Connector, 4-pin terminal block
Connector, 6-pin terminal block
Oscillator
Resistor, 0603, 1%, 560R
Trimmer, potentiometer, 500 kΩ, 23TURN
Resistor, 0603, 240 kΩ, 5%
Resistor, 0603, 200 kΩ, 5%
Resistor, 0603, 2.49 kΩ, 0.1%
6-pin (3 × 2), 2.54 mm header and shorting blocks
2-pin (1 × 2), 2.54 mm header and shorting blocks
20-lead, wide body SOIC
Adjustable voltage regulator
Ferrite beads, 0402
SMA right hand jack
LED, SMD
Schottky diode, 1 A, SMB
Capacitor, ceramic, 1812
Test points, yellow
Rev. 0 | Page 10 of 12
Manufacturer Part Number
Panasonic ERA6AEB122V
Multicomp MCMR04X000 PTL
Yegeo RC0805JR-07120RL
Yegeo RC0805JR-07120RL
AVX 08056C106KAT2A
Multicomp MC0805F104Z160CT
Kemet B45196E3106K309
Yegeo CC0603KRX7R7BB104
AVX 0603YC103KAT2A
Camdenboss CTB5000/2
Camdenboss CTB5000/4
Camdenboss CTB5000/6
LTC LTC6900CS5#TRMPBF
Multicomp CRCW0603560RFKEAHP
Vishay T93YB504KT20
Vishay CRCW0603240KFKEA
Bourns CR0603-FX-2003ELF
Multicomp MC0063W060312K49
Harwin M20-9983646 and M7566-05
Harwin M20-9990246
Analog Devices, ADM2582EBRWZ
Inc.
Analog Devices, ADP667ARZ
Inc.
Taiyo Yuden BKH1005LM182-T
TE Connectivity 5-1814400-1
Avago HSMS-C191
ON Semiconductor MBRS130T3G
TDK C4532C0G3F101K160KA
Vero 20-313140
