EVAL-ADM2582EEMIZ/EVAL-ADM2587EEMIZ User Guide
Table 7. ADM2582E 3.3 V V
Voltage Discrete Capacitor Between GND
EN55022
Frequency QP Level Class A
(MHz) dB (μV/m) dB (μV/m)
179.120 26.7 40
357.172 30.2 47
559.008 31.7 47
714.1080 27.4 47
892.448 33.3 47
80
70
60
50
40
30
20
10
0
30 100
FREQUENCY (MHz)
Figure 8. Horizontal Scan from 30 MHz to 1000 MHz
(Corresponds to Worst Case for Table 7
Test Results (Using a High
CC
and GND )
1 2
Antenna Antenna
Position Height (m) Pass/Fail
Horizontal 4 Pass
Horizontal 3 Pass
Horizontal 2 Pass
Horizontal 1.2 Pass
Horizontal 1 Pass
EN55022
CLASS A
EN55022
CLASS B
1000
Table 8. ADM2582E
Voltage Discrete Capacitor Between GND
Frequency QP Level
(MHz) dB (μV/m)
197.740 23.6
344.228 28
394.000 30.1
425.216 31.6
465.760 32.8
492.064 32.2
496.700 32.8
532.980 25.3
537.196 28.5
537.308 38.8
562.532 38.6
577.768 39.1
583.396 33.9
587.724 27.4
588.056 39.5
603.648 33.5
608.236 39.0
80
70
60
50
40
30
20
10
0
30
Figure 9. Horizontal Scan from 30 MHz to 1000 MHz
Rev. 0 | Page 7 of 12
5.0 V V Test Results (Using a High
CC
EN55022
Class A Antenna
dB (μV/m) Position
40 Horizontal
47 Horizontal
47 Horizontal
47 Horizontal
47 Horizontal
47 Horizontal
47 Horizontal
47 Horizontal
47 Vertical
47 Horizontal
47 Horizontal
47 Horizontal
47 Horizontal
47 Vertical
47 Horizontal
47 Horizontal
47 Horizontal
100
FREQUENCY (MHz)
(Corresponds to Worst Case for Table 8)
UG-916
and GND )
1 2
Antenna
Height (m) Pass/Fail
4 Pass
3 Pass
2.5 Pass
2.2 Pass
2 Pass
2.5 Pass
1.8 Pass
2 Pass
3 Pass
1.5 Pass
1.8 Pass
2 Pass
1.5 Pass
2.5 Pass
1.5 Pass
1.5 Pass
1.5 Pass
EN55022
CLASS A
EN55022
CLASS B
1000
