Levelflex M FMP43

Output signal

Signal on alarm

Linearization

Data of the FOUNDATION
Fieldbus interface
Endress+Hauser

Output

• 4 to 20 mA (invertible) with HART protocol
• PROFIBUS PA:
– signal coding: Manchester Bus Powered (MBP)
– data transmission rate: 31.25 KBit/s, voltage mode
• FOUNDATION Fieldbus (H1):
– signal coding: Manchester Bus Powered (MBP)
– data transmission rate: 31.25 KBit/s, voltage mode
Error information can be accessed via the following interfaces:
• Local display:
– Error symbol
– Plain text display
• Current output, signal on error can be selected (e.g. according to NAMUR recommendation NE43)
• Digital interface
The linearization function of the Levelflex M allows the conversion of the measured value into any unit of
length or volume and mass or %. Linearization tables for calculating the volume in cylindrical tanks are
preprogrammed. Other tables of up to 32 value pairs can be entered manually or semi-automatically.
The creation of a linearization table with FieldCare is particularly convenient.
Basic Data
Device Type
Device Revision
DD Revision
CFF Revision
ITK Version
ITK-Certification Driver-No.
Link-Master (LAS) cabable
Link Master / Basic Device selectable
Number VCRs
Number of Link-Objects in VFD
Virtual communication references (VCRs)
Permanent Entries
Client VCRs
Server VCRs
Source VCRs
Sink VCRs
Subscriber VCRs
Publisher VCRs
Link Settings
Slot time
Min. Inter PDU delay
Max. response delay
1012 (hex)
04 (hex)
02 (hex)
02 (hex)
4.61
www.endress.com / www.fieldbus.org
yes
yes; Default: Basic Devce
24
24
1
0
24
23
0
23
23
4
6
10
9
