Endress+Hauser Levelflex M FMP43 Technical Information page 43

Levelflex M FMP43
Endress+Hauser
Ordering information Levelflex M FMP43
10 Approval:
A Non-hazardous area
1 ATEX II 1/2 G Ex ia IIC T6
7 ATEX II 1/2 G Ex d (ia) IIC T6
5 ATEX II 1/2 G Ex ia IIC T6, ATEX II 1/3 D
3 ATEX II 2G Ex e mb (ia) IIC T6
2 ATEX II 1/2 D, Alu blind cover
4 ATEX II 1/3 D
M FM DIP Cl. II Div. 1 Gr. E-G N.I.
S FM IS Cl. I, II, III Div. 1 Gr. A-G N.I., zone 0, 1, 2
T FM XP Cl. I, II, III Div. 1 Gr. A-G, zone 1, 2
N CSA General Purpose
P CSA DIP Cl. II Div. 1 Gr. G + coal dust, N. I.
U CSA IS Cl. I, II, III Div. 1 Gr. A-D, G + coal dust, N.I., zone 0, 1, 2
V CSA XP Cl .I, II, III Div. 1 Gr. A-D, G + coal dust, N.I., zone 1, 2
K TIIS Ex ia IIC T4 (in preparation)
I NEPSI Ex ia IIC T6 (in preparation)
Y Special version, TSP-No. to be spec.
20 Probe:
300 mm - 4000 mm/12 in - 157 in
K ..... mm, rod 8 mm, 316L, Ra < 0.76 μm/30 μin
M ..... in, rod 8 mm 316L, Ra < 0.76 μm/30 μin
S ..... mm, rod 8 mm, 316L, electropolished Ra < 0.38 μm/15 μin
T ..... in, rod 8 mm 316L, electropolished Ra < 0.38 μm/15 μin
Y Special version, TSP-No. to be spec.
30 O-ring Material; Temperature:
5 EPDM, FDA, USP Cl. VI; - 20 °C to 130 °C
6 Kalrez, FDA, USP Cl. VI; - 20 °C to 150 °C
9 Special version, TSP-No. to be spec.
40 Process Connection:
-- Threaded boss --
U1J Thread M24, 316L, install > accessory weld-in adapter
-- Clamp connections --
TCJ Tri-clamp ISO2852 DN25-38 (1 to 1-1/2"), 316L, 3A, EHEDG
TDJ Tri-clamp ISO2852 DN40-51 (2"), 316L, 3A, EHEDG
TFJ Tri-clamp ISO2852 DN70-76.1 (3"), 316L, 3A, EHEDG
-- Hygienic connections --
T7J SMS 1-1/2" PN25, 316L, EHEDG
TXJ SMS 2" PN25, 316L, EHEDG
MAJ DIN11864-1 A DN25 tube DIN11850, 316L, slotted-nut, EHEDG
MQJ DIN11851 DN40 PN40, slotted-nut, 316L, EHEDG
MRJ DIN11851 DN50 PN40, slotted-nut, 316L, EHEDG
S1J NEUMO BioControl DN25 PN16, 316L, EHEDG
-- ANSI flanges --
AEJ 1-1/2" 150 lbs RF, 316L flange ANSI B16.5
AFJ 2" 150 lbs RF, 316L flange ANSI B16.5
YY9 Special version, TSP-No. to be spec.
50 Power Supply; Output:
B
D 2-wire; PROFIBUS PA
F
G 4-wire 90-250 VAC; 4-20mA SIL HART
H 4-wire 10.5-32 VDC; 4-20mA SIL HART
Y
60
70
2-wire ; 4-20mA SIL HART
2-wire; FOUNDATION Fieldbus
Special version, TSP-No. to be spec.
Operation:
1 W/o display, via communication
2 4-line display VU331
3 Prepared for FHX40
9 Special version, TSP-No. to be spec.
Type of Probe:
1 Compact, basic version
5 Compact, detachable
6 Remote, cable 3 m, detachable
7 Remote, cable 6 m, detachable
9 Special version, TSP-No. to be spec.
43
