Process connection
ø78
ø56
ø39
ø92
ø68
ø51
ø63
ø42,9
ø64
ø30,4
ø127
ø152,4
28
Designation
DIN11851 DN40 PN40
with slotted nut F40*
A
P
= 16 bar
max
Material:
21
A= 1.4307
B= 316L (1.4435)
B
DIN11851 DN50 PN40
with slotted nut F50*
P
= 16 bar
A
max
Material:
22
A= 1.4307
B= 316L (1.4435)
B
DIN11864-1 A DN25
Pipe DIN11850
with slotted nut F25*
A
P
= 16 bar
max
21
Material:
A= 1.4307
B= 316L (1.4435)
B
NEUMO BioControl
DN25 PN16*
P
= 16 bar
max
Material: 316L (1.4435)
1-1/2" 150lbs RF
Flange ANSI B16.5*
P
= 16 bar
max
17,5
Material: 316L
2" 150lbs RF
Flange ANSI B16.5*
P
= 16 bar
max
19,1
Material: 316L
Versions
Approvals
• 0.76 μm
• EHEDG
• 0.76 μm
• 0.38 μm
electropolished
• 0.76 μm
Levelflex M FMP43
Option
MQJ
MRJ
MAJ
S1J
AEJ
AFJ
Endress+Hauser
