Endress+Hauser Levelflex M FMP43 Technical Information page 26

reference point of
measurement
M24 x 1.5
➀
➁
➂
process
connection
(example)
26
Probes - Dimensions and materials
option "1":
compact
➀
Insulator
Material
Ketron PEEK LSG
➁
O-ring (see Feature 30 in "Ordering information"
Material
EPDM Freudenberg 70 EPDM 291
FFKM DuPont Kalrez 6221
➂
Probe (see Feature 20 in "Ordering information)
Material
316L (1.4435)
Hastelloy C22
F12 / T12 / F23 housing
option "6/7":
remote electronic
4 x Ø 8,5
option "5":
compact, detachable
Approval
FDA, 3A,
USP Cl. VI
Approval Temperature range
-20 °C to +130 °C (functional)
-20 °C to +121 °C (3A Class. II, USP Cl. VI)
FDA, 3A,
USP Cl. VI
-20 °C to +150 °C (functional)
-20 °C to +149 °C (3A Class. I, USP Cl. VI)
Version
0.76 μm mechanically polished
0.38 μm electropolished
Special version available on request
Levelflex M FMP43
88
Ø 5
Ø 54
L00-FMP43xxx-06-00-00-en-001
Option
5
6
Option
K, M
S, T
Y
Endress+Hauser
