Equipment architecture

4
Output
The Levelflex is initially adjusted at the factory to the probe length ordered, so that in most cases only the
application parameters, that automatically adapt the device to the measuring conditions, need to be entered.
For models with current output, the factory adjustment for zero point "E" and span is "F" 4 mA and 20 mA.
For digital outputs and the display module, the factory adjustment for zero point "E" and span "F" is 0 % and
100 %. A linearization function with max. 32 points, that is based on a manually or semi-automatically input
table, can be activated onsite or via remote operation. This function enables, for example, the conversion of
the level into units of volume or weight.
Probe selection
Probe type: Rod probe, compact
Standard version
Probe length:
Sideways • 10 Nm with 316L (1.4435)
capacity: • 16 Nm with Hastelloy C22 (on request)
Options:
Feature 70 Option "1"
Rod probe, compact
Slotted nut for separation
from housing
0.3 to 4 m
• Reference probe can be connected (Calibration kit FMP43 -
order number: 71041382)
• Autoclavable (Protective cover FMP43 - order no.: 71041379)
Option "5"
Levelflex M FMP43
Rod probe, remote
Slotted nut for separation
from housing
Option "6, 7"
