Remote display FHX40

46
1
E N
E N
D R
D R
E S
E S
O rd
O rd
er
er
S +
S +
Se
Se
Co
Co
H A
H A
r.- No
r.- No
de :
de :
U S
U S
.:
.:
E R
E R
M es
M es
sb er
sb er
M ea
M ea
su rin
su rin
ei ch
ei ch
g ra
g ra
ng e
ng e
U 16
U 16
m ax
m ax
4. ..2
4. ..2
... 36
... 36
. 20
. 20
V DC
V DC
m
m
0 m
0 m
A
A
IP
6 5
T
T
A
A
>7 0°
>7 0°
C :
C :
t >8
t >8
5° C
5° C
mm (in)
Micropilot M, Levelflex M, Prosonic M
1
Separate housing FHX40 (IP65)
2
Cabel
3
Pipe
4
Note!
For the device families Micropilot FMR2xx, Levelflex FMP4x and Prosonic FMU4x, the remote display FHX40
must be only used for the HART communication version.
Ordering information:
010
Approval
A
Non-hazardous area
2
ATEX II 2G Ex ia IIC T6
3
ATEX II 2D Ex ia IIIC T80°C
G
IECEx zone1 Ex ia IIC T6/T5
S
FM IS Cl.I Div.1 Gr.A-D, zone 0
U
CSA IS Cl.I Div.1 Gr.A-D, zone 0
N
CSA General Purpose
K
TIIS Ex ia IIC T6
C
NEPSI Ex ia IIC T6/T5
Y
Special version, TSP-no. to be spec.
020
Cable
1
20m/65ft; for HART
5
20 m/65 ft (> PROFIBUS PA / FOUNDATION Fieldbus)
9
Special version, TSP-no. to be spec.
030
Additional option
A
Basic version
B
Mounting bracket, pipe 1"/ 2"
Y
Special version, TSP-no. to be spec.
995
Marking
1
Messstelle (TAG), see additional spec.
FHX40 -
Complete product designation
For connection of the remote display FHX40 use the cable which fits the communication version of the
respective instrument.
A
3
120 (4.72)
82 (3.23)
A
Wall mounting (without mounting bracket)
B
Pipe mounting (mounting bracket and plate supplied
optionally, see product structure)
Levelflex M FMP43
B
2
88
(3.46)
118 (4.65)
96 (3.78)
max. 80 (3.15)
min. 30 (1.18)
4
L00-FMxxxxxx-00-00-06-xx-000
Endress+Hauser
