Levelflex M FMP43
Endress+Hauser
F23 housing (seawater-resistant*, corrosion-resistant)
Pos. Part
1
F23 housing
Cover
Sealing
2
Window
Sealing of the glass
Sealing
Cable gland
3
Plug
Adapter
4
Sealing ring
5
Nameplate*
6
Grounding terminal*
7
Screw*
Tag
8
Rope
Crimp sleeve
* Seawater-resistant on request (complete in 316L (1.4404)).
F23 housing
316L (1.4404/1.4435)
3
5
1
6
7
8
4
Material
Housing body: 316L (1.4404); Sensor neck: 316L (1.4435);
earth connection block: 316L (1.4435)
316L (1.4404)
Fa. SHS: EPDM 70pW FKN
ESG-K-Glass (Toughened safety glass)
Silicone sealing compound Gomastit 402
Fa. SHS: EPDM 70pW FKN
Polyamid (PA), CuZn nickel-plated
PBT-GF30
PE
316L (1.4435)
Fa. SHS: EPDM 70pW FKN
304 (1.4301)
Screws: A2; Spring washer: A4; Clamp: 304 (1.4301);
Holder: 301 (1.4310)
A2-70
VA
VA
Aluminium
2
L00-x12xxxx-16-00-00-en-001
Trelleborg: EPDM E7502
1.0718 galvanized
3.1655
Trelleborg: EPDM E7502
31
