44
80
90
100
995
FMP43-
1)
OVP = overvoltage protection
Housing:
A F12 Alu, coated IP68 NEMA6P
B
F23, 316L, IP68, NEMA6P
C T12 Alu, coated IP68 NEMA6P, separate conn. compartment
D T12 Alu, coated IP68 NEMA6P + OVP
Y
Special version, TSP-No. to be spec.
Cable Entry:
2
Gland M20 (EEx d > thread M20)
3
Thread G 1/2
4
Thread NPT 1/2
5
Plug M12
6
Plug 7/8"
9
Special version, TSP-No. to be spec.
Additional Option:
A Basic version
B
EN10204-3.1 material (316L wetted parts) inspection certificate
H 5-point linearity protocol, see additional spec.
J
5-point, 3.1, 5-point linearity protocol, see additional spec.,
EN10204-3.1 material (316L wetted parts), inspection certificate
P
CoC-ASME BPE, EN10204-3.1 material (316L wetted parts) inspection
certificate
R
5-point, CoC-ASME BPE, 3.1, 5-point linearity protocol, see additional spec.,
EN10204-3.1 material (316L wetted parts), inspection certificate
Y
Special version, TSP-No. to be spec.
Marking:
1 Tagging (TAG), see additional spec.
2 Bus address, see additional spec.
Complete product designation
Levelflex M FMP43
1)
, seperate terminal compartment
