Application Kit Manual TC3X7 ADAS
Hardware: Application Kit TC3X7 ADAS V2.0
Features
2.2

Block Diagram

CAN0
CAN
Transceiver
Micro
USB
USB
miniWiggler
LIN
Transceiver
Figure 2-1 Application Kit TC3X7 ADAS Block Schematic
User Manual
Application Kit TC3X7 ADAS V2.0
XTAL
PLL
P10.3 or
P20.8
P10.2 or
P20.7
TC3X7
ADAS
OCDS1
(TC397)
P14.0
TriCore
P14.1
CPU
P10.5
P10.6
Acoustic
4 LED's
Beeper
(P13.0 up to
P13.3)
RGMII (P11, P12)
PHY
Serial to
QSPI0 (P20)
Parallel
converter
SDMMC or QSPI 1 (P10)
RIF0 / IOs
I2C (P15) or QSPI4 (P22)
P33.7
QSPI2 (P15)
2-2
RJ45
Twisted Pair
XGA Display
320x240
with touch
RTC
Multi Voltage System
Supply TLF3068xQVS01
V2.0
2018-06
