Application Kit Manual TC3X7 ADAS
Hardware: Application Kit TC3X7 ADAS V2.0
Signal (on board used) Description
Table 5-6 Peripheral Signals (continued)
Short name
P20.10
P20.11
P50.0 / D1_N
P50.1 / D1_P
P50.2 / D2_N
P50.3 / D2_P
P50.4 / CLK_N
P50.5 / CLK_P
P50.6 / FR_P
P50.7 / FR_N
P50.8 / D3_P
P50.9 / D3_N
P50.10 / D4_P
P50.11 / D4_N
/ESR0
P21.2
P02.0
P00.3
P00.4
P00.6
P00.7
P00.8
P00.9
P02.2
P02.8
P00.2
P00.5
P02.5
P02.6
P02.7
User Manual
Application Kit TC3X7 ADAS V2.0
Description
SDMMC0 Data 2 Input/Output for SD card
SDMMC0 Data 3 Input/Output for SD card
RIF0 LVDS negative RX Input Data Channel 0
RIF0 LVDS positive RX Input Data Channel 0
RIF0 LVDS negative RX Input Data Channel 1
RIF0 LVDS positive RX Input Data Channel 1
RIF0 LVDS negative RX Input Serial Clock
RIF0 LVDS positive RX Input Serial Clock
RIF0 LVDS positive RX Input Frame Clock
RIF0 LVDS negative RX Input Frame Clock
RIF0 LVDS positive RX Input Data Channel 2
RIF0 LVDS negative RX Input Data Channel 2
RIF0 LVDS positive RX Input Data Channel 3
RIF0 LVDS negative RX Input Data Channel 3
MMIC Reset Signal
MMIC OK Signal
MMIC Input/Output Signal 1
MMIC Input/Output Signal 2
MMIC Input/Output Signal 3
MMIC Input/Output Signal 4
MMIC Input/Output Signal 5
MMIC Input/Output Signal 6
MMIC Input/Output Signal 7
MMIC Input/Output Signal 8
QSPI3 Slave Select Output 5 for SPI_CS0 of MMIC
QSPI3 Slave Select Output 4 for SPI_CS1 of MMIC
QSPI3 Slave Select Output 3 for SPI_CS2 of MMIC
QSPI3 Master Receive Input A for SPI_SO from MMIC
QSPI3 Master Transmit Output for SPI_SI of MMIC
QSPI3 Master Clock Output for SPI_SCLK of MMIC
