Clock Signals; Debug Signals; Peripheral Signals - Infineon TC3X7 ADAS Manual

Application Kit Manual TC3X7 ADAS
Hardware: Application Kit TC3X7 ADAS V2.0
Signal (on board used) Description
5.4

Clock Signals

Table 5-4 Clock Signals
Short name
XTAL1
XTAL2
5.5

Debug Signals

Table 5-5 Debug Signals
Short name
/TRST
DAP0
DAP1
P21.6
P21.7
5.6

Peripheral Signals

Table 5-6 Peripheral Signals
Short name
P14.1
P14.0
P10.6
P10.5
P15.4
P15.5
P33.7
P20.7
P20.8
P10.2
P10.3
P11.0
P11.1
P11.2
P11.3
P11.4
P11.5
P11.6
P11.7
P11.8
User Manual
Application Kit TC3X7 ADAS V2.0
Description
Crystal Oscillator Input
Crystal Oscillator Output
Description
Test Reset
Device Access Port Line 0 / Test Data Clock (TCK)
Device Access Port Line 1 / Test Data Select (TMS)
Test Data Input (TDI)
DAP2 / TDO from debug connectors
Description
ASCLIN0 Receive Input A
ASCLIN0 Transmit Output
ASCLIN2 Receive Input D
ASCLIN2 Transmit Output
I2C0 Serial Clock
I2C0 Serial Data Input C und Output
RTC Alarm Interrupt Input
CAN00 Receive Input B (optional)
CAN00 Transmit Output (optional)
CAN02 Receive Input E
CAN02 Transmit Output
Ethernet TXD3 Output
Ethernet TXD2 Output
Ethernet TXD1 Output
Ethernet TXD0 Output
Ethernet TXCLK Output
Ethernet GREFCLK Input
Ethernet TCTL Output
Ethernet RXD3 Input A
Ethernet RXD2 Input A
5-2 V2.0
2018-06
