Connector Pin Assignment

6 Connector Pin Assignment
The Application Kit will be shipped with two 40 pin male (plug) connectors on top layer with a standard grid of
2,54mm.
6.1

I/O connectors TC397 ADAS

X103
(VCC_IN) 1 2
GND 3 4
P21.2 5 6
P14.8 7 8
P14.6 9 10
P21.4 11 12
P02.0 13 14
P02.2 15 16
P02.4 17 18
P02.6 19 20
P02.8 21 22
P00.1 23 24
P00.3 25 26
P00.5 27 28
P00.7 29 30
P00.9 31 32
P00.11 33 34
AN19 35 36
AN17 37 38
AN25 39 40
Figure 6-1 IO connectors for TC397 - Pinout
Note: VCC_IN is connected to X102 and X103 with a 0R resistor which is not assembled by default to avoid
shortcut to 3,3V in case of measurement on the connector. If VCC_IN needed on X102 and X103 then
assemble R113 with a resistor 0R size 0805. Pin 1 of X102 and X103 are always connected together.
Power connector pinout
Figure 6-2 Power connector pinout (Roka 520 2550)
User Manual
Application Kit TC3X7 ADAS V2.0
+3V3
GND
P21.3
P14.7
P20.0
P21.5
P02.1
P02.3
P02.5
P02.7
P00.0
P00.2
P00.4
P00.6
P00.8
P00.10
P00.12
AN18
AN16
AN24
+5,5V...+40V
6-1
X102
P14.5 40 39
P33.10 38 37
P15.7 36 35
P15.5 34 33
P15.8 32 31
P22.3 30 29
P22.1 28 27
P33.11 26 25
P23.3 24 23
P23.1 22 21
P33.6 20 19
P33.12 18 17
P33.2 16 15
P33.4 14 13
AN0 12 11
AN2 10 9
AN11 8 7
AN20 6 5
GND 4 3
+3V3 2 1
GND
P14.4
P33.9
P15.6
P15.4
P15.2
P22.2
P22.0
P23.4
P23.2
P23.0
P33.8
P33.1
P33.3
P33.5
AN8
AN3
AN13
AN21
GND
(VCC_IN)
