Signal (on board used) Description

5 Signal (on board used) Description
For more information about the signals please see the user manual/datasheet for TC3X7 and/or the schematics
of the board.
All not mentioned signals are not used on the board and can be used outside if they are connected to the IO
Connectors see Figure 6-1. Optional marked signals are used only if they are connected (default is that they are
not used on the board).
5.1

Power Signals

Table 5-1 Power Signals
Short name
VCC_IN
VIN
GND
+3V3
+5V
VDD
VDDM
VAREF1
VAREF2
VDD_USB
VDD_FT
5.2

Reset Signals

Table 5-2 Reset Signals
Short name
/PORST
/ESR0
/ESR1
5.3

Config Signals

Table 5-3 Config Signals
Short name
P14.5
P14.2
P14.4
P14.3
P10.5
P10.6
User Manual
Application Kit TC3X7 ADAS V2.0
Description
Supply Input (3,5V...40V)
Input Voltage of Power Supply Device
Ground
Supply Voltage (3,3V)
Supply Voltage (5V)
Core Supply Voltage (1,25V)
ADC Analog Part Supply Voltage (5V or 3,3V selectable via 1R resistors)
ADC Reference Voltage 1 (5V or 3,3V selectable via 4R7 resistors)
ADC Reference Voltage 2 (5V or 3,3V selectable via 4R7 resistors)
Supply Voltage from USB (5V)
Supply Voltage FT2232HL device (3,3V)
Description
Power On Reset
External Service Request 0 (Hardware Reset)
External Service Request 1 (Non Maskable Interrupt)
Description
HWCFG1 (EVR33OFF)
HWCFG2 (EVRCOFF)
HWCFG6 (Pins in tristate / Pins with pull-up)
HWCFG3 (Boot from pins / Boot from Flash BMI)
HWCFG4 (Boot from internal flash)
HWCFG5 (Boot from internal flash )
