Usim_Vdd Characteristics; Current Consumption (3.3V) - SimCom SIM7200 Hardware Manual

V
OL
6.4

USIM_VDD Characteristics

Table 23: USIM_VDD Characteristics
Symbol Parameter
V Output voltage
O
I Output current
O
6.5

Current Consumption (3.3V)

Table 24: Current Consumption(SIM7200E)
Idle(AT+CSCLK=0；AT+CFUN=1）
GSM900
WCDMA
FDD
TDD
Voice Call
GSM 850
GSM 900
DCS1800
DCS1900
GPRS Data
DATA mode, GPRS ( 1 Rx,4 Tx ) CLASS 12 CS4
GSM 850
GSM 900
DCS1800
DCS1900
DATA mode, GPRS ( 3Rx, 2 Tx ) CLASS 12 CS4
GSM 850
GSM 900
DCS1800
DCS1900
EDGE Data
DATA mode, EDGE( 1 Rx,4 Tx ) CLASS 12 MCS9
GSM 850
GSM 900
DCS1800
DCS1900
DATA mode, EDGE( 3Rx, 2 Tx ) CLASS 12 MCS9
GSM 850
GSM 900
DCS1800
SIM7200-PCIe_ Hardware_Design _V1.01
USIM_VDD=2.85V
USIM_VDD=1.8V
USIM_VDD=2.85V
Min
2.75
1.7
-
23.0 mA
21.0 mA
24.0 mA
21.0 mA
PCL5 CH189 <300mA,Typical 250mA
PCL5 CH62 <300mA,Typical 260mA
PCL0 CH698 <250mA,Typical 200mA
PCL0 CH661 <250mA,Typical 190mA
PCL5 CH189 <660mA,Typical 550mA
PCL5 CH62 <660mA,Typical 570mA
PCL0 CH698 <530mA,Typical 460mA
PCL0 CH661 <530mA,Typical 450mA
PCL5 CH189 <500mA,Typical 410mA
PCL5 CH62 <500mA,Typical 400mA
PCL0 CH698 <400mA,Typical 310mA
PCL0 CH661 <400mA,Typical 290mA
PCL8 CH189 <500mA,Typical 375mA
PCL8 CH62 <500mA,Typical 385mA
PCL2 CH698 <450mA,Typical 400mA
PCL2 CH661 <450mA,Typical 390mA
PCL8 CH189 <330mA,Typical 260mA
PCL8 CH62 <330mA,Typical 270mA
PCL2 CH698 <220mA,Typical 260mA
2.4 -
1.35 -
2.4 -
Type
2.85
1.80
-
33
Smart Machine Smart Decision
2.85 V
1.8 V
2.85 V
Max Unit
3.05
V
1.9
150 mA
2016-05-19
