Table 3: Coding schemes and maximum net data rates over air interface

Multislot definition(GPRS/EDGE)
Slot class
1
2
3
4
5
6
7
8
9
10
11
12
GPRS coding scheme
CS 1 = 9.05 kb/s / time slot
CS 2 = 13.4 kb/s / time slot
CS 3 = 15.6 kb/s / time slot
CS 4 = 21.4 kb/s / time slot
EDGE coding scheme
MCS 1 = 8.8 kb/s/ time slot
MCS 2 = 11.2 kb/s/ time slot
MCS 3 = 14.8 kb/s/ time slot
MCS 4 = 17.6 kb/s/ time slot
MCS 5 = 22.4 kb/s/ time slot
MCS 6 = 29.6 kb/s/ time slot
MCS 7 = 44.8 kb/s/ time slot
MCS 8 = 54.4 kb/s/ time slot
MCS 9 = 59.2 kb/s/ time slot
HSDPA device category
Category 1
Category 2
Category 3
Category 4
Category 5
Category 6
Category 7
Category 8
Category 9
Category 10
SIM7200-PCIe_ Hardware_Design _V1.01
DL slot number UL slot number Active slot number
1 1
2 1
2 2
3 1
2 2
3 2
3 3
4 1
3 2
4 2
4 3
4 4
Max data rata（4 slots）
36.2 kb/s
53.6 kb/s
62.4 kb/s
85.6 kb/s
Max data rata（4 slots）
35.2 kb/s
44.8 kb/s
59.2 kb/s
70.4 kb/s
89.6 kb/s
118.4 kb/s
179.2 kb/s
217.6 kb/s
236.8 kb/s
Max data rate（peak）
1.2Mbps
1.2Mbps
1.8Mbps
1.8Mbps
3.6Mbps
3.6Mbps
7.2Mbps
7.2Mbps
10.2Mbps
14.4Mbps
Smart Machine Smart Decision
2
3
3
4
4
4
4
5
5
5
5
5
Modulation type
GMSK
GMSK
GMSK
GMSK
Modulation type
GMSK
GMSK
GMSK
GMSK
8PSK
8PSK
8PSK
8PSK
8PSK
Modulation type
16QAM,QPSK
16QAM,QPSK
16QAM,QPSK
16QAM,QPSK
16QAM,QPSK
16QAM,QPSK
16QAM,QPSK
16QAM,QPSK
16QAM,QPSK
16QAM,QPSK
