20M
TDD
5M
10M
Band38
15M
20M
5M
10M
Band40
15M
20M
Note: In above table the current consumption value is the typical one of the SIM7200 module tested in
laboratory. In the mass production stage, there may be differences among each individual.
6.6

Electro-Static Discharge

SIM7200-PCIe is an ESD sensitive component, so more attention should be paid to the procedure of handling and
packaging. The ESD test results are shown in the following table.
Table 25: ESD characteristics (Temperature: 25
Pin
VCC
GND
Antenna port
USB_DP,USB_DN
RESET
6.7 Radio Characteristics
6.7.1

Conducted Output Power

The following table shows SIM7200-PCIe's conducted output power, comply with 3GPP TS 05.05and TS
34.121.
Table 26: Conducted Output Power
Frequency
GSM850
E-GSM900
DCS1800
PCS1900
GSM850 (8-PSK)
E-GSM900 (8-PSK)
SIM7200-PCIe_ Hardware_Design _V1.01
CH38000 10dBm Typical 190mA
CH38000 10dBm Typical 200mA
CH38000 10dBm Typical 230mA
CH38000 10dBm Typical 230mA
CH39150 10dBm Typical 220mA
CH39150 10dBm Typical 220mA
CH39150 10dBm Typical 250mA
CH39150 10dBm Typical 250mA
Contact discharge
±5KV
±5KV
±5KV
±3KV
±1KV
Max
33dBm ±2dB
33dBm ±2dB
30dBm ±2dB
30dBm ±2dB
27dBm ±3dB
27dBm ±3dB
℃, H umidity:
Air discharge
±10KV
±10KV
±10KV
±6KV
±3KV
Min
5dBm ± 5dB
5dBm ± 5dB
0dBm ± 5dB
0dBm ± 5dB
5dBm ± 5dB
5dBm ± 5dB
35
Smart Machine Smart Decision
45 % )
