SPECIFICATIONS

Voltage Range:
Current @ 13.8VDC:
Load Cell Platforms:
Load Cell Excitation:
Operating Environment:
Enclosure:
Remote Input:
Output Control/ Alarm:
Serial Port:
Internal USB port:
Scale Link Control:
CAN 1 Port:
CAN 2 Port:
Setup & Calibration:
Fuses:
Software Features:
D4204-EN
11V – 36V DC (12V & 24V machinery) with reverse polarity protection
*For systems manufactured on or before 31DEC2017
9.0V – 36V DC (12V & 24V machinery) with reverse polarity protection
*For systems manufactured on or after 01JAN2018
-Limited to 11-16V with SLC2810 or ISOBUS compliant systems
-Gives Low Battery Warning below 11VDC and stops weight display. Recovers and
resumes weighing once voltage is at or above 11VDC.
<0.2A base scale with 4 load cells, up to 5.0A max with active output & all options.
Internal self-resetting fuses for PCB protection & SLC remote protection.
<0.2A ISOBUS SL2 + 4 load cells, no external options
<0.5A ISOBUS SL2 + 16 load cells, no external options
ERM modules add <0.1A to system
SLC2810 adds <0.1A to system
16 Maximum 350 ohm transducers; 1 scale platform x 16 bars, 2 scale platforms x 8
bars each, or 4 scale platforms x 4 bars each
Regulated 8.0VDC, 500mA max, current sensing and overcurrent protected
-40C to +65C (-40F to 149F); 0 to 95% RH non-condensing
*SLC2810 remote display limited to -29C to +60C (-20F to 140F)
IP65 per IEC529 methods (dust and low pressure water resistant)
Detects open or closed switch state based on software setting. 0 – 3,000Hz ground
pulse detection. *+VIN remote input detection not supported at time of publication.
Active high 3.0A continuous with 5.0A surge at system level voltage. Output state
programmable in software.
RS232 Com1 & Com2; 1200 – 115K baud; 7/8 bits; E/O/N parity;
scoreboard/ streaming data; Serial Gross Weight; DS ERM compatible
M12 harness or direct wire based on SL2 model
USB 2.0 A port; FAT32 format; thumb drive size up to 32G
For settings save/ load, software update, and ISOBUS mask update
SPI bus on 8 pin M12 supports proprietary SPI remotes SLC2810 & SLC2400
Primary CAN port; ISOBUS and Universal Terminal (UT) compatible
Proprietary CAN port for connection to other devices or sensors
Use UT or SLC2810 to access and change settings
Main power requires external line fuse. Internal fuses are self-resetting.
Software features are similar to EZIV scales. Refer to D4055 and D4020 for settings
changes, functions, print formats, and feature definitions.
