Dead Weight Calibration from SLC2810 Indicator

Procedure to calibrate with known weight:
WT CAL
3. If the scale capacity is not at least 5%, the system will not accept the calibration value and display the
message "ADD WT". Add more weight to the scale until the 5% capacity weight has been exceeded.
4. After the 5% capacity weight has been reached, the indicator displays the message "CAL". The weight
value estimated to be on the scale at that time is displayed. The weight on the scale is estimated based on
the previous calibration value.
5. Correct the weight value by pressing the
select the digit to change.
NOTE: The scale will not accept the weight entered if motion is detected (weight is not stable) and will display the
error message "MOTION."
6. When the display reads the correct weight, press the
full-scale calibration value. The message "GOOD" is displayed for a successful calibration.
22
1. Enter (D.A.N. 8121)
and press
WT CAL and prompt to zero the scale.
Press and hold the ZERO key for 3
seconds to zero the system.
2. Scale will now prompt "ADD WT". Place
a known weight on system (ex. 5000 lb.
test weight) on the scale platform and
press the
at least 5% of the scale capacity, the
message "CAL" will be displayed.
key to increment the flashing digit and the
key to automatically determine and store the
Scale Link 2 Technical Manual
using numeric key pad
, the SLC2810 will display
key. If calibration weight is
key to
D4204-EN
