MENU 4.2 – PRESET TOLERANCE (JUMP LIST 42)
T MTHD (D.A.N. 4201) Tolerance Method
Select WEIGHT OR PERCENT to activate Tolerance.
TOLER (D.A.N. 4202) Tolerance
The Tolerance feature is a "tolerance window" for the entered preset. For example, if the tolerance is set to 5% and
the preset is 1000 lbs., the "tolerance window" is 50lbs. The scale is in the "tolerance window" when the display is
between 50 and -50 lbs. The auto-advance function activates the Preset Advance Delay Time while the weight is in
the tolerance window. The auto-advance Delay Timer resets every time the weight moves out of the tolerance
window.
RELAY (D.A.N. 4005)
NOTE: Tolerance can be used in any RELAY mode. Refer to
OVERLK (D.A.N. 4203) Tolerance Over Lock
When enabled, prevents the scale from auto-advancing if the amount being loaded or unloaded has exceeded the
preset tolerance amount and has caused the scale to display "OVER".
MENU 4.3 – MIXER REVOLUTIONS (JUMP LIST 43)
TMRCTR (D.A.N. 4301) Timer Counter
Selects if the mix timer or the rotation counter feature will be displayed when the TIMER/COUNTER key is pressed.
DRATIO (D.A.N. 4302) Drive Ratio
The Drive Ratio is a number that tells the indicator how many pulses equal 1 mixer revolution. The drive ratio can be
any number between 0.01 and 999.99.
MENU 5.0 – PORT OUTPUTS (JUMP LIST 5)
Each of the following outputs can be set to any communication port for added flexibility.
RMDPRT (D.A.N. 5001) Remote Display Port
Selects serial remote display output. Off, COM1, COM2, or COM3
EXRPRT (D.A.N. 5003) External Radio Port
Sets external radio port. Off, COM1, COM2, or COM3
PRPORT (D.A.N. 5005) Printer Port
Sets printer port. Off, COM1, COM2, or COM3
SCPORT (D.A.N. 5006) Scoreboard Port
Sets scoreboard port. Off, COM1, COM2, or COM3
OPSTAT (D.A.N. 5007) Opstat Port
Sets opstat port. Off, COM1, COM2, or COM3
CANPRT (D.A.N. 5111) CAN Port
Used to send a specific message via the CAN bus
DBGPRT (D.A.N. 5999) Debug Port
Sets internal debug port. Off, COM1, COM2, or COM3
