RLYOUT (D.A.N. 4008) Relay Out
Selects the state of the relay when a preset is reached. SIG 12V or SIG 0V
PRCLPT (D.A.N. 4009) Preset Clear on Print
When enabled, the preset and preset ID will be cleared when a print occurs. Default setting is ON.
MENU 4.1 – SETPOINT (JUMP LIST 41)
SETOUT (D.A.N. 4101) Gross Set Point Output
Gross Set Point determines when the +12VDC Alarm Output becomes active.
SIG 12V The relay will turn on when the weight is equal to or exceeds the Gross Set Point weight.
SIG 0V The relay will turn off when the weight is equal to or below the Gross Set Point weight.
SETCHG (D.A.N. 4102) Set Point Weight Change
This is the "weight change" required to turn off the +12VDC Alarm Output after it has been activated. This weight
must be lower than the weight entered for SETPNT (from 0-999999). Once the weight on the scale is below the
Gross Set Point by the "weight change" amount, the +12V Alarm Output will change back to the original output (prior
to reaching the gross set point). This setting prevents the +12VDC Alarm Output from repeatedly turning on and off
SETPNT
when mixing around the actual weight.
SETDEL (D.A.N. 4103) Set Point Delay Time
This setting is used with Gross Set Point. This "delay time" must expire before the +12VDC Alarm Output can turn
on or off. The selection ranges from 0 to 10 seconds. This setting prevents the 12VDC Alarm Output from repeatedly
SETPNT
turning on and off when mixing around the actual weight.
SETPNT (D.A.N. 4104) +12VDC Alarm Output
This feature allows the operator to set a Gross weight in the Long Form that will activate the +12VDC Alarm Output
on the power cord. The Set Point weight can range from 0-999999 and uses the Gross weight shown for the Zero
ZEROUT (D.A.N. 2102).
Output feature
SETCTR (D.A.N. 4105) Set Point Counter
This setting is used with Gross Set Point feature and counts the number of times the gross weight on the scale
activates the Gross Set Point. Access the value through the Long Form to display the counter value. Reset the
counter to 0 in the Long Form by pressing 0 on the keypad while the SETCTR value is displayed.
STWTSC (D.A.N. 4106) Set Point Weight Source
This feature allows the operator to select the weight source to trigger the SETPNT.
NORMAL – Displayed weight.
48 Scale Link 2 Technical Manual D4204-EN
