MENU 2.4 – REMOTE DISPLAY (JUMP LIST 24)
RMDISP (D.A.N. 2401) Select Remote Display Type
EZ2 Most Remote Displays, including RD1000 or RD2000
EZ3MUX First Generation RD2400 Remote Display
COG RD2500V Remote Display
RMTERM (D.A.N. 2402) Remote Terminal
ON - Allows external devices to use the Cab Control Communication on a serial "wired" interface.
BARGRP (D.A.N. 2411) Bar Graph Mode
Select how the bar graph works on the RD4000. The bar graph can be set to work for gross weight, presets,
timers/counters, or ingredients.
OFF = No display
RIGHT = Bar graph begins with no display and fills from "left to right"
LEFT = Bar graph begins with a full display and is removed from "right to left"
MIDOUT = Bar graph begins with no display and fills from middle to full display
MIDIN = Bar graph begins with a full display and is removed from full display to middle
NOTE: These settings will also affect the TMR4610 bar graph display.
WTGRPH (D.A.N. 2412) Bar Graph enable
Enables the bar graph for gross weighing mode.
BAR WT (D.A.N. 2413) Bar Graph Weight
Enter the Gross Full-Scale Weight to activate all LED's of the bar graph on the RD4000 remote. This is used with all
Bar Graph Modes. If set to a weight value of 12,000, approximately half of the bar graph will be lit when the gross
weight displayed is 6,000
PRGRPH (D.A.N. 2414) Preset Graph Enable
Enables the bar graph for preset weights.
TMGRPH (D.A.N. 2415) Timer Graph Enable
Enables the bar graph for timers/counters.
INGRPH (D.A.N. 2416) Ingredient Graph Enable
Enables the bar graph for ingredient preset weights.
NONDSR (D.A.N. 2417) Non-Digi-Star Display
This feature adds support for Non-Digi-Star displays. Some remote displays cannot accept the speed at which the
data is transmitted. The feature will slow down the timing to be more compatible with competitors' remote displays.
NOTE: For feature to work correctly Bootloader needs to be version 160725 or newer.
