ABCDSP (D.A.N. 3091) A,B,C,D Display Format
Allows the weight for the ABCD scales to be displayed individually as four "SINGLE" scales (as on previous ABC
scale systems), or always together showing the "TOTAL" (A+B+C+D) or "COMBINED" which also displays the
A+B+C+D weight. The "COMBINED" setting also causes the Balance, Tare, Net and Gross function to be performed
to ALL 4 scales at the same time. Please note: Each input (A,B,C,D) have their own Setup and Calibration and also
scale specific settings.
ABCDSP (D.A.N. 3092) A, B, C Display Format, Gain
Select gain setting to be used for scale platform. (.75mv/v, 3mv/v)
MENU 3.1 – MOTION (JUMP LIST 31)
MOTION (D.A.N. 3101) Motion
When enabled, an annunciator flashes under the word Motion on the display to indicate unstable weight.
The MOTION parameter limits operation if the scale is unstable. It does not correct for the instability. It is up to the
operator to correct the unstable environment. The following items are disabled until the weight is stable:
Printer output
Zero/Balance function
Tare function
Ingredient Auto-advance
Note: Motion is temporarily turned on during all system weight calibrations to insure a stable measurement. It is turned off after
calibration if Off was selected in Motion setup.
MOT WT (D.A.N. 3102) Motion Weight
Standard motion detection will activate when the weight displayed has moved more than "2 display counts" in less
than "2 seconds". The standard motion detection is selected whenever the indicator is first turned ON or the "Motion
Weight" value is set to "0". The "Motion Weight Value" has a range from 0 (OFF) – 999999. The weight value is
either lb or kg depending on settings for Display Units in Long Form Setup.
NOTE: To use Motion Weight, the motion detection feature
MENU 3.2 – ANALOG OUT (JUMP LIST 32)
LOW WT (D.A.N. 3201) Analog Low Weight
For Units with Analog Output
The "LOW WT" setting allows the user to enter the weight value that equals low output limit (4mA or 0V) for the
analog output. The "LOW WT" value must be smaller than the "HIGH WT" value.
44
MOTION (D.A.N. 3101)
Scale Link 2 Technical Manual
in Menu 3 must be On
D4204-EN
