C2 BD (D.A.N. 2211) COM 2 Baud Rate
Sets Com 1 baud rate for 1200 – 115200
C2 PAR (D.A.N 2212) COM 2 Parity
Sets Com 1 parity to EVEN, ODD, or NONE
C2DATA (D.A.N 2213) COM 2 Data Bits
Sets Com 1 data bits or 7 or 8
C2 DLY (D.A.N 2214) COM 2 Delay
Com 2 Delay chooses the number of seconds the printer connected to the 2nd serial port will delay before
advancing to the next print line. Selections are same as for C1 DLY
MENU 2.3 – PRINT (JUMP LIST 23)
TAREAP (D.A.N. 2301) Tare Auto Print
When enabled, print data will be sent to serial port when the indicator "TARE" function is used.
1L PRT (D.A.N. 2302) 1 Line Print
ON - Formats printer output data on one line.
OFF - Formats printer output data in up to two lines.
APRINT (D.A.N. 2303) Auto Print
When enabled, pressing the following keys will automatically print weight values.
ZERO, HOLD, TARE, TR, ID, NET/GROSS, TIMER, M+, RM, CM, and MS. APRINT also works with remote input
settings for both RMINP1 and RMINP2.
TARE, HOLD, NETGRS, M+, and ZERO
Auto Print prints all transactions. This feature also works with wireless transmitters.
PRTFMT (D.A.N. 2304) Print Format
Many data output formats are available. See the end of this manual for more details.
PRTACC (D.A.N. 2305) Print Accumulation
This feature is designed to automatically keep a running total of the weights printed. It is similar to a Memory Plus
(M+) feature, but it is done automatically each time the weight is printed. Another difference from the M+ feature is
that the weight value is always recorded as a positive weight. For example, if the Print Accumulation contained a
value of 5000 and -1500 was printed, the new Print Accumulation value would be 6500 (change the -1500 to +1500
and then add it to 5000 = 6500). The Print Accumulation can be viewed by entering Menu 2 of the Long Form Setup.
Select either the "PRTAC1" or "PRTAC2" print formats to have the Print Accumulation sent to a printer. To clear the
Print Accumulation value, press the Zero key while the PRTACC value is displayed in the Long Form. The Print
Accumulation value is stored in non-volatile memory and will be retained even after the scale is turned off. Also
accessible to view or clear on seed tender indicators after saving FIELD information.
BUFFER (D.A.N. 2306) Print Buffer
ON - Data sent to the printer port is also stored in the scale's non-volatile "record" memory. When this setting is
accessed in the Long Form, the percentage of the available record memory is displayed.
