ERM settings

DAN 2003: Turns on External Radio Module; 900, 2.4, WiFi. ERM must be on COM2 (default).

Remote input IP1 settings

The remote input IP1 on SL2 can be set for ON/OFF detection as well as pulse detection. It can also be used to
activate multiple SL2 functions such as hold, tare, or print. DAN 1401 selects between these functions.
DAN 1401 = MIXCTR. This is RPM or pulse mode. Ground level pulses are detected. The input pulses are used
by the SL2 based on other software settings such as relay, timer, or counter functions.
DAN 1401 = SWITCH. This is the on/ off mode. SWITCH is detecting ground state. DAN 1402 lets you edit the
message to be displayed when switch is active. DAN 1403 sets the state which is to be detected, open or closed.
*+VIN remote input detection is not supported at time of manual publication.

Output/ FET OP1 settings

The output control OP1 for SL2 has a FET (relay) that drives the output at +VIN up to 3.0A continuous. Output state
programmable to PRESET or SETPNT in software.
DAN 4005: Sets relay to PRESET or SETPNT. PRESET is a pulsed alarm output activated once a preset weight
value is reached. SETPNT is a programmable alarm state.
DAN 4006: Sets seconds of delay for a PRESET to clear.
DAN 4008: Sets high or low output for alarm state. The inactive/ non-alarm mode is kept in the opposite state until
the alarm is activated. Default is +VIN active when alarm is activated (SIG12V).
DAN codes 4101, 4102, 4103, and 4104 are used to dial in the SETPNT operation.
-4101 sets when the output becomes active, over or under the set weight.
-4102 sets the weight change or movement required to deactivate the alarm.
-4103 sets the delay time before the alarm is allowed to turn off.
-4104 sets the weight at which the alarm will activate.
*PREACT and PRNOPA functions not supported at time of manual publication.
