R1STAT (D.A.N 1413) REMOTE INPUT 2 SWITCH STATE
Determines if the Remote Switch Message or Alarm Output lamp is displayed/illuminated for an 'OPEN' or
'CLOSED' condition on the remote input line of the remote port. The default setting is 'CLOSED'.
R1TIME (D.A.N. 1414) REMOTE INPUT 2 SWITCH TIME
Used to set how often the Remote Switch Message 2 is displayed for an 'OPEN' or 'CLOSED' condition on the remote
input line of the power cord. For the default value of 2, the message is displayed every 2 seconds. The maximum
setting is 9 seconds.
MENU 1.9 – DIAGNOSTIC 1 (JUMP LIST 19)
LCDIAG (D.A.N. 1997) Load cell diagnostic
This feature will display a load cell diagnostic screen when connected to a UT. (ScaleLink models)
Information displayed includes the following: Measured Load cell current, number of connected load cells, excitation
voltage, IC supply voltage, and input voltage.
PRG ID (D.A.N. 1998) Program ID
This feature will display the indicator model and the program ID currently loaded. This will be displayed repeatedly
until a key is pressed.
EST WT (D.A.N. 1999) Estimated Weight
This feature sets the gross weight to a new value. Use this feature when the scale has been accidentally Zero
Balanced or if a scale indicator is replaced and the gross weight on the scale is known.
MENU 2.0 – COMMUNICATIONS, REMOTE, & ISOBUS (JUMP LIST 2)
REMOTE (D.A.N. 2001) Remote
When enabled, will send display data to a standard Cab Control Remote. When set to MTLINE, the contents of the
3-line display will also be sent.
NOTE: This setting will need to be enabled in to use Remote Terminal functionality (RMTERM – D.A.N 2402)
SCL NO (D.A.N. 2002) Wireless Scale Number
This number is used to identify this specific indicator to the Cab Control unit and the Datalink software. Up to 48
different numbers can be selected.
EXTRAD (D.A.N. 2003) External Radio
This enables the option for an indicator with a J905 port, to attach an external radio or WiFi module. The external
radio or WiFi module will communicate with Cab Control units and Datalink in the same manner as an internal radio.
The WiFi modules will also communicate with smartphone and tablet apps.
DDL (D.A.N. 2004) DDL
When enabled, allows connection of a DDL (Data Downloader) to an indicator with a serial port.
EZ2AUD (D.A.N. 2005) EZ2 Audible Commands
When enabled, an audible notification sounds when an EZ2 command is sent or received.
