PWM option performance
Null current
Center deadband (optional)
Full stroke current capability
*
Step current
*
Customer specified. Reference Ordering Information.
±5 mA maximum if not switched (12 Vdc models)
±8 mA maximum if not switched (24 Vdc models)
±3º nominal
Step current occurs at end of deadband.
