Technical Information
MCHXXX
Ordering information
Connector option
Code Description
1
Terminal strip
2 Pigtail 1524 mm [60 in] without connector
3
Pigtail with unsealed Delphi connector
6 Pigtail with sealed Delphi connector, 4 pin male and
female
7
Pigtail sealed Delphi connector
8
Pigtail sealed DEUTSCH connector
© Danfoss | February 2017
Pigtail (or leadwire) is routed from the control handle to a Delphi environmental connector. Pigtail
minimum length is 381 mm [15 in].
For optional connectors, contact your Danfoss representative.
Suffix number
The factory generates these final three numbers. To create the suffix number, supply the following
information:
•
Supply voltage
•
Number of additional switches needed and actuation angle of each with respect to null
•
Full current output
•
Resistance of the driven load
•
Step current needed (if necessary)
For details regarding unique configurations, contact your Danfoss representative.
Detail
Electrical connections are made to a set of four internal or more screw terminals
depending on the specific model.
Four wires extend from the handle case.
Reference Potentiometer option on page 14 for lengths.
The wires from the case terminate in a Delphi environmental connector.
Reference Potentiometer option on page 14.
There are two separate connectors, each connects to a separate potentiometer.
The wires from the case terminate in a sealed Delphi connector.
The wires from the case terminate in a sealed DEUTSCH connector.
11022667 | BC00000033en-US0601 | 7
