Place the Cable Cover slightly higher than the cavity in the

lower part of the Spring Arm, and slide the Cable Cover

down so that the Hooks on the Cable Cover slide into the

Clips in the Spring Arm. (Figure 20)

Spring

Arm

Hook

Cable

Cover

Hook

Figure 20

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
