Line up the three holes on the top of the Grommet Base
2.
Plate with the holes on the bottom of the Spring Arm (1).
Insert three of the Clamp Screws (10) through the Grommet
3.
Base Plate and into the bottom of the Spring Arm.
Use the 4 mm Hex Key (12) to tighten the Clamp Screws.
4.
(Figure 8)
Spring Arm
Grommet Base
Plate
Grommet
Screw
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
Figure 8
23
Clamp
Screw
4 mm
Hex Key
