Appendix D - About Firmware

Network Parameters Configuration Menu

Option 'n' from the "Diagnostics and Configuration" menu displays the "Network Parameters
Configuration" menu, described in
displayed by using option'd', and the network parameters are configured by using option 'c'.
While configuring, the MAC Address should be set to the MAC address on the Connectcore
processor board. Appropriate values to the IP address, subnet mask, gateway IP address and the
Ethernet settings should be provided, to match the TCP/IP network corresponding to the local IT
environment.

Diagnostics Tests Menu

Option 't' from the "Diagnostics and Configuration" menu displays the "Diagnostics &
Manufacturing Tests" menu. This menu provides several test options. The menu options are
described in Figure 8: Diagnostics and Manufacturing Tests Menu.
92
Figure D.3. In this menu, the TCP/IP network parameters are
Figure D.3 Network Parameters Configuration Menu
Figure D.4 Diagnostics and Manufacturing Tests Menu
98-1031 Rev AA Series IV Concentrator U and I Guide
