and configuration mode. The details of this configuration are explained in Concentrator Diagnostics
Mode. The following figure describes boot-up.

Diagnostics Mode

During the startup, the following question displays on the console:
If the input is 'y', the concentrator goes into diagnostics mode. The diagnostic mode has limited
functionality. The WAN port and the LAN port are not activated in this mode. This mode helps the
user to:
• Configure the concentrator;
• Browse and capture the Ramlog; and
• Perform diagnostics tests.
Diagnostics modes are described in the following sections.
Diagnostics Mode
The diagnostics mode provides more diagnostics. In addition, this mode provides option to configure
the TCP/IP Network Parameters.
Series IV Concentrator U and I Guide
Boot up to Diagnostics Mode ...? (y/n)y
98-1031 Rev AA
Figure D.1 Boot Up
Figure D.2 Diagnostics Mode
