Landis+Gyr

Remote Antenna Cable

If you need to install antennas remotely from the concentrator, there is a cable designed specifically
for this purpose

Wood Pole Mount Installation

The utility or municipality determines the final guidelines of where to install the concentrator. Know
and follow the utility or municipality guidelines before installing the concentrator and antennas.

Wood Pole Mounting Kit

In addition to your chosen concentrator assembly kit, you need a mounting kit.
Series IV Concentrator U and I Guide
Table 4-4. Remote Antenna Cable
Part Number
19-2200
Table 4-5. 45-1091 Kit, Mounting, Wood Pole, Concentrator
98-1031 Rev AA
Description
CBL ASSY,REMOTE
ANT,5 FT,N
Part Name
Number
NUT, HEX, FLANGE 1/
101983-025
4-20UNC, SS
Chapter 4 - Concentrator Installation
Qty
0
Ref only
Quant
ity
4
31
