Streetlight Arm Horizontal Mount Installation

The utility or municipality determines the final guidelines of where to install the concentrator. Know
and follow the utility or municipality guidelines before installing the concentrator and antennas.

Concentrator Streetlight Arm Mounting Kit

In addition to your chosen concentrator assembly kit, you need a mounting kit.
Series IV Concentrator U and I Guide
Table 4-7. 45-1049 KIT, HORIZONTAL MOUNTING,METAL POLE, CONCENTRATOR
Image Part Number Name
CBL, ASSY, STREET
103826-000
LIGHT, Gridstream, 4FT
CBL ASSY,REMOTE
19-2200
ANT,5 FT,N
19-1013
CBL, ASSY, Remote
Antenna
1 foot
TIE WRAP, 28inch,
22-0375
NYLON, WHITE
98-1031 Rev AA
Chapter 4 - Concentrator Installation
Quantity
0,
ref only
0
Ref only
2
3
43
