Chapter 3 - Field Configuration
Concentrator Configuration
Follow the steps for configuring the Concentrator:
1. Plug the concentrator programming cable into the left-most barrel connector on the concentrator.
2. Plug the serial cable labeled "Console" into the COM 1 port on the PC
.
16
Figure 3 - 1. Concentrator with programming cable
Figure 3 - 2. Serial cable plugged into COM 1
98-1031 Rev AA
Series IV Concentrator U and I Guide
Landis+Gyr
