E
About Programming and
Diagnostic Cables
Landis+Gyr offers multiple cable options for performing system upgrades and configuration. The
following table outlines tasks each cable can perform.
Cable
19-1185
19-1126
Series IV Concentrator U and I Guide
Table E-1. Update Cables
LPP
Upload DCWs,
Upload new
firmware, and
configure the
Gridstream radio
inside the
concentrator.
Upload DCWs,
Upload new
firmware, and
configure the
Gridstream radio
inside the
concentrator.
98-1031 Rev AA
Console
Configure EEPROM
settings in the
concentrator CPU,
which includes the
Concentrator Net and
Node ID (aka MCC
Net and Node), Event
Manager Net, and
Node settings.
Configure EEPROM
settings in the
concentrator CPU,
which includes the
Concentrator Net and
Node ID (aka MCC
Net and Node), Event
Manager Net, and
Node settings.
Ethernet
Can do a direct FTP
download of
concentrator CPU
firmware via cable
connection. Use a
router, computer, and
Ethernet cables.
No Ethernet
connectivity. Perform
upgrades over the air.
You must have a WAN
network setup with a
Take Out Point (TOP),
and the Cellnet
system running on the
system controller.
