5
RF Filter Enable/Disable and
Battery Replacement Kit
The Series IV radio has an integrated RF Filter that can be enabled/disabled whenever necessary.
This chapter outlines the procedure to perform this task. It also outlines the battery replacement kit
and procedure.

Enable/Disable RF Filter

When the integrated RF filter is required for reducing interference, the filter can be enabled or
disabled in the field by qualified support personnel using RadioShop 4.1.
1. Verify that the Concentrator is highlighted on the Nodes Pane.
2. Right-click the Concentrator ID.
3. Select Enable RF Filter from the pop-up menu.
Series IV Concentrator U and I Guide
This procedure is only for the WAN radio (Series IV IWR) and not the BLT3 (LAN)
radio.
Figure 5 - 1. Enable (or Disable) the RF Filter
98-1031 Rev AA 47
