heat-timer MPC Platinum Installation And Operation Manual page 48

WIRINg: MPC PLATINUM TO A MOTORIzED VALVE
C O R P O R A T I O N
MENU FUNCTIONS
SELECT enters menus or accepts changes
ADJUST selects menu items or changes settings
BACK returns to previous menu
DAY selects next day
PREV./NEXT steps through output status
ENCLOSED
ENERGY
MANAGEMENT
EQUIPMENT
LISTED
99RA
OUTPUT RATINGS:
120VAC, 6A RESISTIVE
1A PILOT DUTY
15A TOTAL
FOR ALL CIRCUITS
INPUT RATINGS:
115VAC 60Hz
30VA MAX
USE COPPER WIRE,
CLASS 1 WIRE ONLY
2
SAFETY
GROUND
MUST BE
CONNECTED
MADE IN U.S.A.
Earth
Ground
L
120 VAC
N
120 VAC
24 VAC
Transformer
Since each installation is unique, Heat-Timer Corp is not responsible for any installation related to any electrical or
piping diagram generated The provided illustrations are to demonstrate the control operating concept only
48
R
MPC
Platinum
MON 12/01/2010
Cycle On 13/15
Cutoff = 55
o
OD = 31 F
AUTO
HELP PREV.
BYPASS
(DEL)
AUX
OUTPUT SYS CLOCK
3 4 5 6 7 8 9 10 11
B R W BURNER SYSTEM
CLOCK
MOTORIZED
VALVE
Combustion
Air-Damper
Floating
Valve Actuator
DO NOT APPLY ANY VOLTAGE
TO SENSOR TERMINALS
ALL SENSORS MUST BE
GOLD SERIES SENSORS
ADJUST
10:01Am
PRESS TO
SELECT
o
F Day
o
SYS = 138 F
BACK
NEXT
DAY
OPTION OPTION OPTION
1 2 3
12 13 14 15 16 17 18
AUX OPTION OPTION OPTION
1 2 3
ROUTE SENSOR AND AUXILIARY WIRES
THROUGH THIS KNOCKOUT ONLY
MPC Platinum Settings:
• Operation Mode = Burner or Valve
• Thermal Lockout = On
• System Run-On = 2 Minutes
ALERT
MPC Platinum Installation and Operation Manual
INPUTS
T
A1
System Sensor
SYSTEM
TEMP
A2
Sensor Shield
A3
SHUTDOWN
A4
A5
PROVE
A6
NETWORK
A7
MSI CONNECTION
ON BACK
A8
A9
AUX
INPUT 0
A10
T
A11 Outdoor Sensor
OUT
TEMP
A12
Sensor Shield
A13 T
AUX
TEMP 0
A14
A15 T
AUX
TEMP 1
A16
A17 T
AUX
TEMP 2
A18
Prove
from Damper
End-Switch
