BACNET COMMUNICATION FEATURES

The MPC Platinum BAC (with BACnet IP and BACnet MSTP connections) has many features and benefits.
• Boiler and Sensor status, values, and settings. Provides "Live" status and editing capability of Platinum control settings and values
from the BACnet network.
• The Data collected can be used to create a historical log, and trigger alarms.

BACNET COMMUNICATION

(Requires BACnet Communication Package)
SELECT: MENU/<Settings>/<More Settings>/<Remote Interface>/Network Settings
• Before connecting the Platinum control to the BACnet network, the user must set the
following parameters according to the BACnet Network Administrator's instructions.
MODBUS capable Platinum controls will display --NETWORK PANEL--
on the 2nd row of the display when in screen saver mode

SELECTING BACNET IP OR BACNET MSTP

SELECT: MENU/.../ Network Settings/Switch to IP or MSTP
• The same Platinum control can operate within a BACnet IP or BACnet MSTP network.
• To switch to BACnet IP from the MSTP menu, select the Switch to IP option.
• To switch to BACnet MSTP from the IP menu, select the Switch to MS/TP option.
BACNET IP CONFIGURATION
• Any Heat-Timer Platinum control can come as or be upgraded to communicate over a
BACnet IP network either directly or through a gateway with the BACnet IP driver.
• Using a gateway is beneficial when communicating to a proprietary protocol EMS/BMS
system. The gateway must have both drivers, the BACnet IP or MSTP and the proprietary
protocol.

BACNET DEVICE ID

• This is a 32 bit unique number within the BACnet network. It identifies the Platinum
control within the BACnet network. The BACnet Network Administrator must provide that
information.

IP AND MASk ADDRESSES

• The Platinum control IP address must be unique within the IP network.
• The Network Administrator needs to provide both of the IP and Mask addresses.
• Leaving the IP and Mask Addresses blank or 000.000.000.000 enables a DHCP server to
assign the addresses.
• If no DHCP server is active, the control must use a static IP and Mask. Enter the IP address
in the IP field and the Mask in the Msk field. After dialing each octet , press the ADJUST/
SELECT button to accept and move on to the next octet.
BACNET MSTP CONFIGURATION
• Any Heat-Timer Platinum control can come as or be upgraded to communicate over a
BACnet MSTP network either directly or through a gateway with the BACnet MSTP driver.
• Using a gateway is beneficial when communicating to a proprietary protocol EMS/BMS
system. The gateway must have both drivers, the BACnet IP or MSTP and the proprietary
protocol.
BACNET DEVICE ID
• This is a 32 bit unique number within the BACnet network. It identifies the Platinum
control within the BACnet network. The BACnet Network Administrator must provide that
information.
MPC Platinum Installation and Operation Manual
ALERT
--NETWORK SETTINGS-
BACnet ID:
MS/TP Address:
Baud: 9600
Switch to IP
--NETWORK SETTINGS-
BACnet ID:
IP: 192.168.001.015
Msk: 255.255.255.000
Switch to MS/TP
--NETWORK SETTINGS-
BACnet ID:
IP: 192.168.001.015
Msk: 255.255.255.000
Switch to MS/TP
--BACNET DEVICE ID--
1
[
----- IP ADDRESS -----
000 . --- . --- . ---
--- ADDRESS MASK ---
000 . --- . --- . ---
--NETWORK SETTINGS-
BACnet ID:
MS/TP Address:
Baud: 9600
Switch to IP
--BACNET DEVICE ID--
1
[
1
1
5
5
]
1
1
]
37
