Mpc Platinum Function Chart - heat-timer MPC Platinum Installation And Operation Manual

Digital display shows the cycle status,
outdoor cutoff, outdoor, and system temperatures.
To view and adjust settings, press the
Adjust/Select button.
C O R P O R A T I O N
MENU FUNCTIONS
SELECT enters menus or accepts changes
ADJUST selects menu items or changes settings
BACK returns to previous menu
DAY selects next day
PREV./NEXT steps through output status
AUTO
ENCLOSED
BYPASS
ENERGY
MANAGEMENT
EQUIPMENT
LISTED
99RA
OUTPUT
OUTPUT RATINGS:
120VAC, 6A RESISTIVE
1A PILOT DUTY
15A TOTAL
FOR ALL CIRCUITS
INPUT RATINGS:
115VAC 60Hz
30VA MAX
USE COPPER WIRE,
CLASS 1 WIRE ONLY
2 3 4
B
MOTORIZED
VALVE
SAFETY
GROUND
MUST BE
CONNECTED
MADE IN U.S.A.
120VAC
Power
BYPASS position runs
Green Earth
the output.
Ground screw
* DRY CONTACT ONLY
** Only available with the Remote Communications package
MPC Platinum Installation and Operation Manual

MPC PLATINUM FUNCTION CHART

Depress the knob to move
forward through the menus and to
accept changes. To change a
setting's value, rotate the knob.
R
MPC
Platinum
MON 12/01/2010
Cycle On 13/15
o
Cutoff = 55 F
o
OD = 31 F SYS = 138
HELP PREV.
(DEL)
AUX
SYS CLOCK
5 6 7 8 9 10 11 12
R W
BURNER SYSTEM AUX
CLOCK
Valve and Burner
Outputs are active
when MPC requires
steam
INPUTS
DO NOT APPLY ANY VOLTAGE
TO SENSOR TERMINALS
ALL SENSORS MUST BE
GOLD SERIES SENSORS
ADJUST
10:01Am
PRESS TO
SELECT
Day
o
F
BACK
NEXT
DAY
OPTION OPTION OPTION
1 2 3
13 14 15 16 17 18
OPTION OPTION OPTION
1 2 3
ROUTE SENSOR AND AUXILIARY WIRES
THROUGH THIS KNOCKOUT ONLY
OPTION outputs can be programmed
to operate additional equipment or
Internet Modem.
Operates additional equipment based
on a separate Aux Schedule
Depress the button to go back
through the menus
T
A1
SYSTEM
From heating system sensor
TEMP
A2
When closed, outputs
A3
SHUTDOWN
are turned off*
A4
Checks status of system
A5
PROVE
components*
A6
From Heat-Timer network
A7
NETWORK
MSI CONNECTION
sensors**
ON BACK
A8
A9
AUX
From DHW Control*
INPUT 0
A10
From outdoor sensor
T
A11
OUT
TEMP mounted in the shade
A12
A13 T
AUX
TEMP 0
A14
Remote Communication
A15 T
AUX
TEMP 1
Option**
A16
T
A17
AUX
TEMP 2
A18
Red lights indicate when the
associated stage relay
is activated
3
