MPC
Platinum NAME
OBj ID
2700 TLOCKOUT
2800 XYZMIN
2900 XYZTEMP
3000 ZMAXTGT
MPC Platinum Notes
♦ AV=analog value(2), BV=binary value(5), MV=multi-state value(19)
Note: The device object id is set through the menus The device object name is 'HTC_' followed by the panel serial
number
Note:
All objects with multiple UOM's depend upon the value of INMODE to determine which one to use
Note: Use XYZMIN when OPMODE is set to District Steam Use XYZTEMP, HDIFF and TLOCKOUT when OPMODE
is set to Burner/valve
Note: Use BOOSTADJ when BOOSTMODE is set to VariDay and VariDayNight Use BOOSTTIME when
BOOSTMODE is set to ManualBoost
Note:
The MPC Platinum has a schedule, which is 7-days, 4 day/night pairs per day For example: Instance 2000 is
the first DAY schedule of Monday; Instance 2001 is the first NIGHT schedule of Monday; Instance 2008 is the
first DAY schedule of Tuesday; Instance 2009 is the first NIGHT schedule of Tuesday and so on.
Note: Use the MPC Platinum installation menu for supplementary information
MPC Platinum Installation and Operation Manual
DESCRIPTION
Thermal Lockout Enable
District Steam Delay
System Setpoint
Max Target Temperature
RANGE / STATES /
TYPE ♦
UOM
SPECIAL VALUES
BV 0=OFF, 1=ON
AV Minutes(72) 0 - 30
AV °C(62), °F(64) 21 - 122°C, 70 - 250°F
AV °C(62), °F(64) 32 – 116°C, 90 – 240°F
READ
ONLY
