MS/TP ADDRESS/ MAC ADDRESS

• This is the MSTP MAC address on a RS485 network. Its MSTP range is 1 though 127. It is a
unique address within the network.
• The MS/TP address must be provided by the Network Administrator.

MSTP BAUD RATE

Options: 9600, 19200, 38400
• The Baud determines the speed of communication.
• Both the Platinum control and BMS must use the same Baud rate.
• The communication is fixed to 8 Data Bits, No Parity, and 2 Stop Bits.

MPC PLATINUM BACNET VARIABLE LIST

MPC
Platinum NAME
OBj ID
0 BOOSTADJ
100 BOOSTMODE
200 BOOSTTIME
300 BPTIME
400 BYPASSMODE
500 CLENGTH
600 DADJUST
700 DCUTOFF
800 DLS
900 FAULTMODE
1000 HDIFF
1100 INMODE
1200 NADJUST
1300 NCUTOFF
1400 ODTEMP
1500 ODTRIM
1600 OPMODE
1700 OUTPUT
1800 PDATE
1900 PTIME
2000 SCHEDULES00
through through
2055 SCHEDULES55
2100 SEASON
2200 SHIFT
2300 SRUNON
2400 SYSSEN
2500 SYSTEM
2600 SYTRIM
38
DESCRIPTION
Vari-Boost Adjustment
Boost Mode
Manual Boost Time
Bypass Time
Bypass Mode
Cycle Length
Day Heat Adjustment
Outdoor Day Cutoff
Day Light Saving
Sensor Fault Mode
System Differential
Sensor Mode
Night Heat Adjustment
Outdoor Night Cutoff
Outdoor Sensor
Outdoor Sensor Trim
Operation Mode
Output Relay
Panel Date
Panel Time
Schedules
Season
Day/Night Shift
System Run-on
System Sensor
System Relay
System Sensor Trim
Default: 9600
RANGE / STATES /
TYPE ♦
UOM
SPECIAL VALUES
AV none (95) 0 1 - 6 4
1=BoostOff, 2=ManualBoost,
MV
3=VariDay, 4=VariDayNight
AV Minutes(72) 0 - 120
AV Minutes(72) 0 - 2,147,483,647
BV 0=AUTO, 1=ON
AV Minutes(72) 10 - 240
1=A, 2=B, 3=C, 4=D, 5=E, 6=F,
MV 7=G, 8=H, 9=I, 10=J, 11=K,
12=L,13=M, 14=N, 15=O, 16=P
AV °C(62), °F(64) -6 - 38°C, 20 - 100°F
BV 0=Enable, 1=Disable
BV 0=OutputOn, 1=OutputOff
AV °C(62), °F(64) 2 - 42°C, 3 - 75°F
BV 0=°F, 1=°C
1=A, 2=B, 3=C, 4=D, 5=E, 6=F,
MV 7=G, 8=H, 9=I, 10=J, 11=K,
12=L,13=M, 14=N, 15=O, 16=P
AV °C(62), °F(64) -6 - 38°C, 20 - 100°F
AV °C(62), °F(64) -40 - +122°C, -40 - +250°F
AV °C(62), °F(64) -3 - +3°C, -5 - +5°F
0=Burner/valve, 1=District
BV
Steam
BV 0=Off, 1=On
Days (70)
AV 0 - 2,147,483,647
since 1/1/1981
Minutes(72)
AV 0 - 1439
since 0:00
Minutes(72)
AV 0 - 1439, 1440=empty schedule
since 0:00
BV 0=Winter, 1=Summer
1=To-Day, 2=To-Night,
MV
3=Extend-Day, 4=To-Schedule
AV Minutes(72) 0 - 60
AV °C(62), °F(64) -40 - +122°C, -40 - +250°F
BV 0=Off, 1=On
AV °C(62), °F(64) -3 - +3°C, -5 - +5°F
MPC Platinum Installation and Operation Manual
--MAC ADDRESS--
1
[
--NETWORK SETTINGS-
BACnet ID:
MS/TP Address:
Baud: 9600
Switch to IP
READ
ONLY
]
1
1
X
X
X
X
X
