Note: All of the member IP addresses must be in the same subnet as the probe targets.
9. Click Update. Repeat these steps for each of the other listed team members.
10. Click Apply/Exit.

Saving and Restoring a Configuration

To save a configuration
1. From the File menu, select Team Save As.
2. Type the path and file name of the new configuration file, and then click Save (a .bcg extension is added).
The configuration file is a text file that can be viewed by any text editor. The file contains information about
both the adapter and the team configuration.
To restore a configuration
1. From the File menu, select Team Restore.
2. Click the name of the file to be restored, and then click Open.
Note: If necessary, go to the folder where the file is located.
3. Click Apply.
4. Click Yes when the message is displayed indicating that the network connection will be temporarily
interrupted.
5. If a configuration is already loaded, a message is displayed that asks if you want to save your current
configuration. Click Yes to save the current configuration. Otherwise, the configuration data that is currently
loaded is lost.
Note: The team may take a very long time to restore if the team is configured with many VLANs and
a static IP address.
